Voltage(V) / Amp

120-240VAC / 54 A – 27 A

Frequency (Hz)

60

Rated AC Output (kW)

6.5

Max. Output AC (kW)

6.8

Power Factor cos¢

1

Output DC (V/A)

12vdc /6 A

Engine Model

MDLA192

Type of Engine

Motor diésel de 4 tiempos, mono cilíndrico, refrigerado por aire

Ignition system

Eléctrico con batería / Manual con jalador

Displacement (cc)

499cc

Engine power

12 Hp

Engine Speed (rpm)

3600

Lubricant Capacity (L）

1.65 (15w-40)

Fuel Tank Capacity（L）

12.5

Hours of continuous operation (h)

5

Fuel consumption (g/kW h)

≤280

Noise (7 meters away) dB(A)

≤82

Dimension（L×W×H)(mm)

740×475×590

Net weight (recoil)(kg)

109

Packaging dimensión (L×W×H)(mm)

780×555×650

Total weight (kg)

115

Opcional

CABIN TO LOWER NOISE LEVEL
